Centrifuge

Centrifuge
English
Model PETRO-CF 363 PETRO-CF 363 VFD PETRO-CF 452
Bowl Diameter (mm) 360 360 360
Bowl Length(mm) 1 271 1 271 1 105
Max. Capacity 45 45 57
Effective Capacity 30 30 40
Max Bowl Speed 3 900 3 900 1 800
Typical Bowl Speed 3 200 0~3 200 1 800
Max G-Force 3 063 3 063 815
Typical G-Force 2 062 0~2 062 815
Separation point 2~5 2~5 5~7
Differential Speed 40 0~40 32
Gearbox Torch 3 500
Gear Box Ration 57:1
Main Drive Motor 37 37 45
Back Drive Motor 11 11 -
Recommend Pump 7.5 7.5 11
Control panel Стандарт Exd
Weight 3 300 2 500 2 634
Dimension(mm) 3 414 х 1 516 х 1 430 3 383 х 990 х 1 562 3 274  х1 090 х 1 653
